Product Description
Company Info
Basic Info.
Model NO.
YN27C
Certification
CE, ISO 9001:2008
Condition
New
Motor
Pneumatic
Drill Hole Diameter
<100mm
Drill Hole Depth
<100m
Bit Type
Button Bit
Drilling Way
Rotary
Net Weight
27kgs
Overall Dimension
746*315*229mm
Type of Engine
Single Cylinder, Air Cooled Two Strokes
Cylinder Diameter*Stroke of Piston
58*70mm
Rotating Speed of Engine
2450r/Min
Displacement of Engine Piston
185cm³
Type of Carburetor
Hand Needle Valve, No Floating Type
Ignition System
Controllable Silicon, Contactless System
Drilling Speed (Mean Value of Five Holes
≥250mm/Min
Drilling Hole Diameter
Φ28-42mm
Fuel Consumption
≤0.121L/M
Tank Capacity
≥1.14L
Drill Rod and Breaker Shank
Hexagonal 22*108mm
Rotating Speed of Drill Rod
≥200r/Min
Trademark
ODM, OEM
Specification
746*315*229mm
Origin
China
HS Code
84303900
Product Description
Product Detail:
Technical Specification:
Specifications | Yn27c | Yn27P | Yn30A |
Weight | 27kgs | 25kgs | 27kgs |
Overall Dimensions | 746*315*229mm | 730*315*229mm | 746*315*229mm |
Function | Drill and Split | Split | Drill |
Rotating Speed | ≥2450r/min | ≥2600r/min | ≥2700r/min |
Displacement of engine piston | 185cm3 | 185cm3 | 185cm3 |
Drill Speed | ≥250mm/min | / | ≥250mm/min |
Drilling hole diameter | φ28-42mm | / | φ28-42mm |
Max drilling depth | 6M | / | 6M |
Fuel consumption | ≤1.2L/h | ≤1.2L/h | ≤1.2L/h |
Tank capacity | ≥1.14L | ≥1.14L | ≥1.14L |
Product Description:
Rock Cement Pavement Impact Crusher
Slick Joint
Convert Wrenches
Start Roping
Economic:
Only 1.5 litres fuel for 1 hour work.Ready for Action:
Delivered in a protective wooden case.
Only 1.5 litres fuel for 1 hour work.Ready for Action:
Delivered in a protective wooden case.
Versatile:
Easily dig all kinds of rock and stone.
Easily breaks up asphalt and concrete into small pieces.
Easily dig all kinds of rock and stone.
Easily breaks up asphalt and concrete into small pieces.
